Introduction：
The filter tank is made of PP material by injection molding, and the filter bracket is made of imported CFRETFGE material. Used for solid - liquid separation of acid and alkali corrosive materials. Main features: acid and alkali resistance, high temperature resistance, corrosion resistance, idling resistance, no leakage, low noise, high efficiency, long service life. Widely used in electronic components and chemical industry pre-filtration.
Specification:
Outlet and inlet diameter：Chinese standard or Japanese standard
Connection Type: Union, Flange
Material：PP
Gasket / O-ring：EPDM, VITON
Filter cartridge：Pleated filter cartridge
Typical Applications:
Electronic industry: PCB, LED, etc.
Chemical industry: coating, metal and plastic plating, waster water and waster gas treatment, etc.
Technical parameters:
YLD-1001
YLD-1004
YLD-2001
YLD-2004
YLD-2006-1
Plating tank（ton））
0.2
0.6
0.4
0.8
1-2
Flow rate（L/min)
15
60
30
80
150
Material
PP
PP
PP
PP
PP
Quantity of filter cartridge（Length * Quantity）
10”×1
10”×4
20”×1
20”×4
20”×6
Max operating temperature（0℃）
＜70
＜70
＜70
＜70
＜70
Pumping power
45W
180W
65W
260W
0.75KW
Size
Length（A)
520
620
520
620
760
Width（B）
310
385
310
385
450
Overall height（mm)
790
900
1015
1080
1420
Weight（KG)
16
28
18
31
75
Outlet and inlet diameter
3/4”
1”
3/4”
1”
1-1/2”
Item / model
YLD-2008-1
YLD-2008-2
YLD-2012-2
YLD-2018-3
YLD-3018-5
Plating tank（ton））
1-2
15-3
2.5-4
4-6.5
6.5-7.5
Flow rate（L/min)
180
220
250
330
500
Material
PP
PP
PP
PP
PP
Quantity of filter cartridge（Length * Quantity）
20”×8
20”×8
20”×12
20”×18
30”×18
Max operating temperature（0℃）
＜70
＜70
＜70
＜70
＜70
Pumping power
0.75KW
1.5KW
1.5KW
2.2KW
3.75KW
Size
Length（A)
760
760
800
800
800
Width（B）
450
450
580
580
580
Overall height（mm)
1420
1420
1420
1420
1760
Weight（KG)
82
86
118
118
128
Outlet and inlet diameter
1-1/2”
1-1/2”
1.5”
2”
2”
